Performance regression on sysbench write benchmarks from 10.2 to 10.3

    XMLWordPrintable

Details

    Description

      I noticed reduced performance numbers when running somewhat large update_no_index sysbench benchmark, when comparing 10.2 to 10.3
      Here is the setup

      • Windows Azure VMwith 16 virtual CPUs, 32GB RAM and SSD storage (I used Local temporary disk)

      Intel(R) Xeon(R) CPU E5-2673 v4 @ 2.30GHz
      Sockets: 1
      Virtual processors: 16

      • MariaDB 10.2.14 vs 10.3.7 (recent build of 4a5e23e257e229b548599133dbed5162af9df6d9)
        the relevant part of my.ini file is as follows

        [mysqld]
        back_log=500
        max_connections=4096
        max_prepared_stmt_count=500000
        table_open_cache=10000
        transaction_isolation=REPEATABLE-READ
        innodb_status_file=0
        innodb_buffer_pool_size=20G
        innodb_log_file_size=15G
        innodb_log_buffer_size=1000M
        innodb-io-capacity=4000
        innodb-io-capacity-max=5000
        innodb_doublewrite=0
        innodb-page-cleaners=1
        innodb-buffer-pool-instances=1
        innodb_adaptive_flushing=0
        innodb_adaptive_flushing_lwm=10


      • sysbench 0.4 (I mention it because current versions of sysbench do not run on Windows anymore, but we do not need anything from the current versions)

      The update-no-index run on a single large table (50 mio rows), with number of users ranging from 1 to 4096, in powers of 2

      Loading table, sysbench prepare

      sysbench --test=oltp --oltp-table-size=50000000 --mysql-host=localhost --mysql-db=sbtest --mysql-user=root --mysql-password= --db-driver=mysql --mysql-table-engine=innodb --max-time=300 --oltp-test-mode=complex --oltp-read-only=off --max-requests=0 --oltp-point-selects=0 --oltp-simple-ranges=0 --oltp-sum-ranges=0 --oltp-order-ranges=0 --oltp-distinct-ranges=0 --oltp-index-updates=0 --oltp-delete-inserts=0 --oltp-non-index-updates=1  --oltp-skip-trx=on --oltp-dist-type=uniform --mysql-socket=MySQL  --num-threads=1 prepare


      sysbench run

      sysbench --test=oltp --oltp-table-size=50000000 --mysql-host=localhost --mysql-db=sbtest --mysql-user=root --mysql-password= --db-driver=mysql --mysql-table-engine=innodb --max-time=300 --oltp-test-mode=complex --oltp-read-only=off --max-requests=0 --oltp-point-selects=0 --oltp-simple-ranges=0 --oltp-sum-ranges=0 --oltp-order-ranges=0 --oltp-distinct-ranges=0 --oltp-index-updates=0 --oltp-delete-inserts=0 --oltp-non-index-updates=1  --oltp-skip-trx=on --oltp-dist-type=uniform --mysql-socket=MySQL  --num-threads=%N% run


      where %N% is 1,2,4,8,16,32,64,128,256,512,1024,2048,4096

      The test takes a nap of 80 seconds between runs, and also between load and first test, and as far as I can see it is enough for all Innodb backgroup IO activity to finish (MB/sec goes down to 0 on a disk where test is ran). Due to innodb-flush-log-at-trx-commit being default (1), the test does not appear to be very CPU bound (sysbench and mysql use 70% of all available 16 CPUs, in windows measurement, i.e over 10 CPUs are busy)

      Below are the results from the runs, for 10.2.4 and recent 10.3.7
      UPDATE: marko mentioned the git 1a62c8a39647db00283b4e35fb6db3c7bc31e3ca as the version right before 10.3 switched to lockless, so
      I added a column for it too. It appears to be better than 10.3.7, but worse than 10.2.14

      Users TPS 10.2.14 TPS 10.3.7 10.3-pre-lockless
      1 1549.92 1547.75 1551.07
      2 2373.89 2209.05 2334.80
      4 4466.03 4276.46 4446.64
      8 9069.82 8587.59 9098.95
      16 16631.45 15719.70 16231.39
      32 28989.79 27482.44 27786.32
      64 36996.12 34843.23 35089.44
      128 37287.05 35172.49 36223.68
      256 38038.01 35896.52 36818.22
      512 38360.71 36567.07 37195.47
      1024 38265.25 36328.62 37253.98
      2048 39990.85 36328.62 38572.81
      4096 41988.71 39032.83 39606.38

      (also see the graph https://docs.google.com/spreadsheets/d/1VqRYCwF4QATCKEKwxKuCcvRXKm2GWnICCdv4fSo4_IU/edit#gid=0)
      It is not as big as I thought initially (somehow I counted 15%, and it is more like 5%), but it is consistent starting from 64 users, and keeping until the 4K . So it needs investigating.
      It is odd because the test itself is not CPU bound, nor IO bound, the bottleneck in my understanding is waiting for flush in log_write_up_to() . I did not try to make it CPU bound by relaxing durability, this might be another exercise, however with increased TPS purging can become more of a bottleneck, and disturb the picture.

      I tried to do some initial profiling (based on CPU sampling), and this is what showed up.

      Below., in all places, baseline refers to 10.2.14, and *comparison" is 10.3.7

      Exclusive samples comparison
      Individual functions (or, exclusive sample percentage with threshold 1% difference)

      Comparison Column Delta Baseline Value Comparison Value
      ut_delay 4.02 16.05 20.07
      l_find 2.44 0.16 2.60
      PolicyMutex<TTASEventMutex<GenericPolicy> >::enter 2.42 0.18 2.60
      TTASEventMutex<GenericPolicy>::enter -4.42 4.42 0.00
      SleepConditionVariableCS -5.41 28.70 23.29

      In short, more busy wait ut_delay, less lazy wait SleepConditionVariableCS . There is a new quite visible function (4th most expensive individual functions now), l_find , which seems to come from replacing stl with custom hashtable in innodb.
      Inclusive samples comparison
      Comparing inclusive samples with 1% difference threshold, gives the below table, which gives me a vague idea that there something is more expensive in purge, and again that lazy wait was replaced with busy wait somewhere, background threads probably use more CPU , for example "coordinator" purge thread. foreground use less of it (as shown by decreased time in do_command for example)

      Comparison Column Delta Baseline Value Comparison Value
      PolicyMutex<TTASEventMutex<GenericPolicy> >::enter 28.69 2.53 31.22
      ut_delay 4.02 16.05 20.07
      trx_purge 3.81 5.67 9.48
      srv_do_purge 3.80 5.70 9.49
      row_purge 3.66 0.00 3.67
      row_purge_step 3.47 0.71 4.18
      que_thr_step 3.31 0.94 4.25
      srv_purge_coordinator_thread 3.25 6.37 9.63
      trx_sys_t::clone_oldest_view 3.18 0.00 3.18
      btr_cur_search_to_nth_level_func 3.12 0.00 3.12
      row_purge_record_func 2.94 0.00 2.94
      row_purge_upd_exist_or_extern_func 2.77 0.00 2.77
      row_purge_reset_trx_id 2.72 0.00 2.72
      que_run_threads_low 2.70 1.73 4.43
      que_run_threads 2.69 1.75 4.45
      l_find 2.46 0.18 2.64
      ReadView::snapshot 2.30 0.00 2.30
      rw_trx_hash_t::iterate 2.27 0.00 2.27
      lf_hash_iterate 2.25 0.00 2.25
      srv_task_execute 2.12 1.95 4.08
      row_purge_reposition_pcur 1.53 0.00 1.53
      row_search_on_row_ref 1.33 0.00 1.33
      btr_pcur_open_low 1.31 0.00 1.31
      btr_search_guess_on_hash 1.31 1.54 2.85
      trx_purge_wait_for_workers_to_complete 1.10 1.52 2.62
      trx_undo_assign_low 1.07 0.00 1.07
      mtr_t::commit 1.05 2.57 3.62
      mtr_t::Command::execute 1.01 2.42 3.43
      srv_worker_thread -1.09 9.84 8.75
      sync_array_wait_event -1.29 9.69 8.40
      trx_write_serialisation_history -1.34 2.62 1.28
      trx_commit_low -1.39 3.15 1.76
      innobase_commit -1.75 47.36 45.61
      trx_commit -1.75 4.79 3.04
      ha_commit_one_phase -1.76 47.55 45.78
      commit_one_phase_2 -1.76 47.54 45.77
      trans_commit_stmt -1.80 48.68 46.88
      ha_commit_trans -1.80 48.65 46.84
      btr_cur_search_to_nth_level -1.85 1.85 0.00
      innobase_commit_ordered_2 -2.04 5.17 3.13
      trx_commit_for_mysql -2.05 5.10 3.05
      innobase_commit_low -2.05 5.11 3.06
      Prepared_statement::execute_loop -2.05 74.58 72.52
      mysql_stmt_execute_common -2.14 74.85 72.71
      mysqld_stmt_execute -2.15 74.89 72.74
      mysql_execute_command -2.21 73.03 70.81
      trx_undo_assign_undo -2.24 2.24 0.00
      Prepared_statement::execute -2.24 74.03 71.79
      threadpool_process_request -2.32 81.71 79.38
      dispatch_command -2.33 79.21 76.88
      do_command -2.34 81.33 79.00
      tp_callback -2.38 82.66 80.28
      srv_resume_thread -3.33 7.94 4.61
      os_event::wait_low -4.98 28.41 23.43
      SleepConditionVariableCS -5.41 28.70 23.29
      TTASEventMutex<GenericPolicy>::enter -30.49 30.49 0.00
