Results using the latest point releases with both low-concurrency (1 thread) and high concurrency (40 threads). Not much is new, other than I have results from new versions:

• I still get better QPS in some cases by adding innodb_log_write_ahead_size=4k to my.cnf
• I don't see many regressions from old to new MariaDB at low concurrency, so it has done great at avoiding CPU regressions
• I still see big regressions from old to new MariaDB at high concurrency, so mutex contention is an issue and the changes to InnoDB seems to be the cause
• the big regressions occur more for read-heavy than for write-heavy and in many cases modern MariaDB (10.5+) gets less than half of the QPS vs older MariaDB. The big regressions for read-heavy arrive in 10.5 and things haven't improved since then

All of the my.cnf files I use are archived here:

• for the low concurrency tests
• for the high concurrency tests

The gists I link to below use a naming pattern like x.ma110502_rel_withdbg.z11b_c8r32.pk1 and x.ma110502_rel_withdbg.z11b_lwas4k_c8r32.pk1. For now ignore the "x." at the start and the ".pk1" at the end. The "ma110502_rel_withdbg" means:

• MariaDB ("ma")
• 11.5.2 ("110502")
• a build that used CMAKE_BUILD_TYPE=RelWithDebInfo
• my.cnf is my.cnf.cz11b_lwas4k_c8r32 (see here)

The links that follow have results in terms of relative QPS (rQPS) which is: (QPS for my version / QPS for older MariaDB). When I look at results across MariaDB major versions then the base case is 10.2.44. When I look at results only for 10.5 point releases then the base case is 10.4.34. When the relative QPS is 1.0 then QPS has not changed, when it is much less than 1.0 then there is a large regression.

First up is the results for the latest point releases at low concurrency. For point releases that support innodb_log_write_ahead_size I include results with it set to =4k and with it not set. The results are here and modern MariaDB almost always has relative QPS >= 0.9 which is OK.

For low concurrency with a focus on MariaDB 10.5 see here which has numbers for 10.5.0, 10.5.4, 10.5.10, 10.5.20, 10.5.24 and 10.5.27. The reason to share the results at low concurrency is to show there aren't big regressions in 10.5 at low concurrency in contrast to the results below that I share.

And note that my focus is on 10.5 because that is where the big regressions first arrived. They are still here, but to understand the root cause I need to show where they start.

Next up is results from the latest. point releases at high concurrency (40 threads) on a server with 48 cores (real cores, AMD SMT is disabled). The relative QPS numbers are here. In the worst cases the relative QPS drops to ~0.4 in 10.5 and has remained there through 11.7. This means older MariaDB gets ~2.5X more QPS than modern MariaDB:

• points-covered-pk - fetch 1 row by PK on a covering index
• points-notcovered-pk - fetch 1 row by PK on a non-covering index
• random-points with range =100 and =1000 - point queries that fetch many rows via a covering index using SELECT with an IN-list
• range-notcovered-si - do a short range scan on a non-covering secondary index

Results from the classic sysbench transaction are here. With them the relative QPS in modern MariaDB is 0.83 or 0.88 depending on the length of the range queries it uses. The regressions here arrived in 10.11 and not much changes since then. If you only use classic sysbench then you will miss some of the large regressions, because the regressions here are smaller than above.

A few write-heavy tests also have large regressions, but they aren't as bad as the results mentioned above

• insert - relative QPS is 0.79, these arrived in 10.11
• update-index - relative QPS is 0.80 in 11.7, these arrived in 10.5 but perf improved a bit since then
• update-inlist - relative QPS is 0.48 in 11.7, these arrived in 10.5, then got worse in 10.11 and have been stable (not getting better) since then

Results from 10.5 point releases are here for high concurrency. I tried all point releases from 10.5.0 through 10.5.10, the even number point releases from 10.5.12 through 10.5.26 and then 10.5.27. I won't annotate them other than to say that the big regressions for read-heavy microbenchmarks arrived prior 10.5.10

I will repeat tests on the large server to collect thread stacks (PMP) and flamegraphs

Aggregated thread stacks from PMP on the 48-core server with sysbench using 40 threads and a cached workload. All of the aggregated thread stacks ("hierarchical") are in subdirectories here.

From random-points.range1000 for 10.4.34 and 10.5.27 and the obvious problem is the most frequent thread stack for 10.5.27 which is mutex contention on the InnoDB LRU (buf_page_make_young). And the problem is the same for random-points.range100, points-covered-pk, points-notcovered-pk and range-notcovered-si. The problem is still there with 11.4.4

futex_wait,__GI___lll_lock_wait,___pthread_mutex_lock,inline_mysql_mutex_lock,buf_page_make_young,buf_page_make_young_if_needed,buf_page_get_low,btr_cur_search_to_nth_level,btr_pcur_open_with_no_init_func,row_search_mvcc,ha_innobase::index_read,handler::ha_index_read_map,handler::read_range_first,handler::multi_range_read_next,Mrr_simple_index_reader::get_next,DsMrr_impl::dsmrr_next,QUICK_RANGE_SELECT::get_next,rr_quick,READ_RECORD::read_record,sub_select,do_select,JOIN::exec_inner,JOIN::exec,mysql_select,handle_select,execute_sqlcom_select,mysql_execute_command,Prepared_statement::execute,Prepared_statement::execute_loop,Prepared_statement::execute_loop,mysql_stmt_execute_common,mysqld_stmt_execute,dispatch_command,do_command,do_handle_one_connection,handle_one_connection,pfs_spawn_thread,start_thread,clone3

But range-notcovered-si has two threadstacks with buf_page_make_young in the top 2 – one for lock, one for unlock – see here for 10.5.27 and the problem remains in 11.4.4.

For insert there is more mutex contention in 10.5.from the InnoDB redo and the binlog – the top N stacks are here for 10.4.44 and 10.5.27. The problem remains in 11.4.4.

For update-inlist the stacks are here for 10.4.34 and 10.5.27 and there is just more mutex contention from InnoDB in 10.5.27. The problem remains in 11.4.4.

Another round of results are here with a cached database, small server, and sysbench using 1 thread. The numbers are the relative QPS which is (QPS for my version / QPS for MariaDB 10.2.44). Mostly I see a few small regressions and a few small improvements. The largest improvement is from setting innodb_log_write_ahead_size for 10.11 through 11.7.

This has results for:

• ma100244_rel_withdbg.z11a_c8r32 - 10.2.44 with the z11a_c8r32 config
• ma100339_rel_withdbg.z11a_c8r32 - 10.3.39 with the z11a_c8r32 config
• ma100434_rel_withdbg.z11a_c8r32 - 10.4.34 with the z11a_c8r32 config
• ma100527_rel_withdbg.z11a_c8r32 - 10.5.27 with the z11a_c8r32 config
• ma100620_rel_withdbg.z11a_lwas4k_c8r32 - 10.6.20 with the z11a_c8r32 config
• ma101110_rel_withdbg.z11a_lwas4k_c8r32 - 10.11.10 with the z11a_c8r32 config
• ma110404_rel_withdbg.z11b_lwas4k_c8r32 - 11.4.4 with the z11b_c8r32 config
• ma110502_rel_withdbg.z11b_lwas4k_c8r32 - 11.5.2 with the z11b_c8r32 config
• ma110602_rel_withdbg.z11b_lwas4k_c8r32 - 11.6.2 with the z11b_c8r32 config
• ma110701_rel_withdbg.z11b_lwas4k_c8r32 - 11.7.1 with the z11b_c8r32 config

The my.cnf files are in the subdirectories here. The differences in them are:

• z11a_c8r32 uses innodb_flush_method while z11b_c8r32 uses the new options (innodb_log_file_buffering etc)
• the 11.6.2 and 11.7.1 config files add innodb_snapshot_isolation=OFF

And this has results for a few more configs (see here)

• z11a_lwas4k_c8r32 - adds innodb_log_write_ahead_size=4096, see this issue
• z11a_si_c8r32 - adds innodb_snapshot_isolation=ON
• z11b_lwas4k_si_c8r32 - adds innodb_log_write_ahead_size=4096 and innodb_snapshot_isolation=ON

I don't see an impact from enabling or disabling snapshot isolation. I do see an impact from innodb_log_write_ahead_size=4096 but that is explained in issue 33894.

In https://github.com/MariaDB/server/pull/3522 I tried to address the observed contention in buf_page_make_young() by tweaking the buffer pool LRU replacement policy. It helped in one test workload but caused performance regressions in others. I think that the way forward would be to concentrate on one test case where that tweak causes a regression. I think that it had better be a read-only workload, so that it can be more deterministic. My hypothesis is that the regression occurs because we are evicting too recently used pages, causing more frequent reloading of pages.

There are some other performance bottlenecks around dict_sys.latch (MDEV-35000, MDEV-34999, MDEV-34988, MDEV-33594), which are more straightforward to fix. Those ought to be largely independent of any buf_pool.mutex contention, though.
