Uploaded image for project: 'MariaDB Server'
  1. MariaDB Server
  2. MDEV-16962

Assertion `!error || !ot_ctx.can_recover_from_failed_open()' failed in open_purge_table upon concurrent ALTER and FLUSH

Details

    Description

      Note: Run with --repeat=N --mem. N can vary a lot, there are periods when it fails for me every time within 5 attempts, and sometimes it takes over 100. Luckily the test is very fast when in runs in shm, so set a really big number for starters.

      --source include/have_innodb.inc

      CREATE TABLE t1 (
        pk SERIAL,
        c VARCHAR(128),
        d DATE,
        vd DATE AS (d) VIRTUAL,
        PRIMARY KEY(pk),
        KEY(vd,c)
      ) ENGINE=InnoDB;
      INSERT IGNORE INTO t1 (pk,c) VALUES (1,'foo');

      --connect (con1,localhost,root,,test)
      REPLACE INTO t1 (pk,c) VALUES (1,'bar');

      --connection default
      --send
        ALTER TABLE t1 ADD FULLTEXT KEY(c), ALGORITHM=COPY;
      --connection con1
      FLUSH TABLES;

      # Cleanup
      --disconnect con1
      --connection default
      --reap
      DROP TABLE t1;


      10.3 8716bb3b72b

      mysqld: /data/src/10.3/sql/sql_class.cc:4672: TABLE* open_purge_table(THD*, const char*, size_t, const char*, size_t): Assertion `!error || !ot_ctx.can_recover_from_failed_open()' failed.
      180818  1:17:07 [ERROR] mysqld got signal 6 ;

      #7  0x00007f5a635fdee2 in __assert_fail () from /lib/x86_64-linux-gnu/libc.so.6
      #8  0x00005602b08e90ab in open_purge_table (thd=0x7f5a28000b00, db=0x7f5a48ff70a0 "test", dblen=4, tb=0x7f5a48ff7240 "t1", tblen=2) at /data/src/10.3/sql/sql_class.cc:4672
      #9  0x00005602b0f6f72b in innodb_acquire_mdl (thd=0x7f5a28000b00, table=0x7f5a0c1502f8) at /data/src/10.3/storage/innobase/handler/ha_innodb.cc:20738
      #10 0x00005602b0f6f926 in innodb_find_table_for_vc (thd=0x7f5a28000b00, table=0x7f5a0c1502f8) at /data/src/10.3/storage/innobase/handler/ha_innodb.cc:20793
      #11 0x00005602b0f6fe99 in innobase_allocate_row_for_vcol (thd=0x7f5a28000b00, index=0x7f5a0c196e88, heap=0x7f5a48ff7670, table=0x7f5a48ff7680, record=0x7f5a48ff7688, storage=0x7f5a48ff7678) at /data/src/10.3/storage/innobase/handler/ha_innodb.cc:20947
      #12 0x00005602b111b01e in row_vers_build_clust_v_col (row=0x7f5a28014108, clust_index=0x7f5a0c133158, index=0x7f5a0c196e88, heap=0x7f5a28014030, vcol_info=0x5602b4adfd08) at /data/src/10.3/storage/innobase/row/row0vers.cc:465
      #13 0x00005602b111c1b0 in row_vers_old_has_index_entry (also_curr=true, rec=0x7f5a5d3fc07f "", mtr=0x7f5a48ff7ab0, index=0x7f5a0c196e88, ientry=0x7f5a28014698, roll_ptr=16888498624468088, trx_id=0, vcol_info=0x5602b4adfd08) at /data/src/10.3/storage/innobase/row/row0vers.cc:959
      #14 0x00005602b10d09f8 in row_purge_poss_sec (node=0x5602b4adfb68, index=0x7f5a0c196e88, entry=0x7f5a28014698, sec_pcur=0x7f5a48ff8050, sec_mtr=0x7f5a48ff82b0, is_tree=false) at /data/src/10.3/storage/innobase/row/row0purge.cc:346
      #15 0x00005602b10d16cb in row_purge_remove_sec_if_poss_leaf (node=0x5602b4adfb68, index=0x7f5a0c196e88, entry=0x7f5a28014698) at /data/src/10.3/storage/innobase/row/row0purge.cc:597
      #16 0x00005602b10d1bb3 in row_purge_remove_sec_if_poss (node=0x5602b4adfb68, index=0x7f5a0c196e88, entry=0x7f5a28014698) at /data/src/10.3/storage/innobase/row/row0purge.cc:710
      #17 0x00005602b10d1dc0 in row_purge_del_mark (node=0x5602b4adfb68) at /data/src/10.3/storage/innobase/row/row0purge.cc:784
      #18 0x00005602b10d32d9 in row_purge_record_func (node=0x5602b4adfb68, undo_rec=0x5602b4ae0118 "", thr=0x5602b4adf998, updated_extern=false) at /data/src/10.3/storage/innobase/row/row0purge.cc:1178
      #19 0x00005602b10d3616 in row_purge (node=0x5602b4adfb68, undo_rec=0x5602b4ae0118 "", thr=0x5602b4adf998) at /data/src/10.3/storage/innobase/row/row0purge.cc:1245
      #20 0x00005602b10d39c4 in row_purge_step (thr=0x5602b4adf998) at /data/src/10.3/storage/innobase/row/row0purge.cc:1331
      #21 0x00005602b1057484 in que_thr_step (thr=0x5602b4adf998) at /data/src/10.3/storage/innobase/que/que0que.cc:1046
      #22 0x00005602b10576b7 in que_run_threads_low (thr=0x5602b4adf998) at /data/src/10.3/storage/innobase/que/que0que.cc:1108
      #23 0x00005602b10578a8 in que_run_threads (thr=0x5602b4adf998) at /data/src/10.3/storage/innobase/que/que0que.cc:1148
      #24 0x00005602b11248fb in srv_task_execute () at /data/src/10.3/storage/innobase/srv/srv0srv.cc:2437
      #25 0x00005602b1124aa0 in srv_worker_thread (arg=0x0) at /data/src/10.3/storage/innobase/srv/srv0srv.cc:2485
      #26 0x00007f5a652d4494 in start_thread (arg=0x7f5a48ff9700) at pthread_create.c:333
      #27 0x00007f5a636ba93f in clone () from /lib/x86_64-linux-gnu/libc.so.6


      Note: The provided test case does not fail on 10.2 for me (still fails on 10.3), however the assertion failure has been observed on 10.2 as well, so I'm adding it to the list of affected/to-be-fixed versions.

      Example of 10.2 failure, ab1ce2204e959bea596817494e932754ab5cbe88

      Version: '10.2.19-MariaDB-debug-log'  socket: '/home/travis/logs/vardir/mysql.sock'  port: 19300  Source distribution
      mysqld: /home/travis/src/sql/sql_class.cc:4404: TABLE* open_purge_table(THD*, const char*, size_t, const char*, size_t): Assertion `!error || !ot_ctx.can_recover_from_failed_open()' failed.
      181020  9:19:58 [ERROR] mysqld got signal 6 ;

      #3  0x00007f98a6eaeca2 in __assert_fail () from /lib/x86_64-linux-gnu/libc.so.6
      #4  0x000056466a9f376c in open_purge_table (thd=0x7f98a0002260, db=0x7f98860e34e0 "test", dblen=4, tb=0x7f98860e3680 "t5", tblen=2) at /home/travis/src/sql/sql_class.cc:4404
      #5  0x000056466aedd338 in innodb_acquire_mdl (thd=0x7f98a0002260, table=0x7f98a05809b8) at /home/travis/src/storage/innobase/handler/ha_innodb.cc:21417
      #6  0x000056466aedd53b in innodb_find_table_for_vc (thd=0x7f98a0002260, table=0x7f98a05809b8) at /home/travis/src/storage/innobase/handler/ha_innodb.cc:21472
      #7  0x000056466aeddac3 in innobase_allocate_row_for_vcol (thd=0x7f98a0002260, index=0x7f98a0208ac8, heap=0x7f98860e3af0, table=0x7f98860e3b00, record=0x7f98860e3b08, storage=0x7f98860e3af8) at /home/travis/src/storage/innobase/handler/ha_innodb.cc:21627
      #8  0x000056466b06235f in row_vers_build_clust_v_col (row=0x7f98a0080e00, clust_index=0x7f98a009e898, index=0x7f98a0208ac8, heap=0x7f98a0080c80, vcol_info=0x56466d18b820) at /home/travis/src/storage/innobase/row/row0vers.cc:470
      #9  0x000056466b063431 in row_vers_old_has_index_entry (also_curr=true, rec=0x7f989436f2c1 ' ' <repeats 49 times>, mtr=0x7f98860e3f60, index=0x7f98a0208ac8, ientry=0x7f98a0724af8, roll_ptr=9851624223149860, trx_id=10079, vcol_info=0x56466d18b820) at /home/travis/src/storage/innobase/row/row0vers.cc:966
      #10 0x000056466b01d7ee in row_purge_poss_sec (node=0x56466d18b680, index=0x7f98a0208ac8, entry=0x7f98a0724af8, sec_pcur=0x7f98860e4510, sec_mtr=0x7f98860e4770, is_tree=false) at /home/travis/src/storage/innobase/row/row0purge.cc:346
      #11 0x000056466b01e42a in row_purge_remove_sec_if_poss_leaf (node=0x56466d18b680, index=0x7f98a0208ac8, entry=0x7f98a0724af8) at /home/travis/src/storage/innobase/row/row0purge.cc:604
      #12 0x000056466b01e90a in row_purge_remove_sec_if_poss (node=0x56466d18b680, index=0x7f98a0208ac8, entry=0x7f98a0724af8) at /home/travis/src/storage/innobase/row/row0purge.cc:717
      #13 0x000056466b01eb11 in row_purge_del_mark (node=0x56466d18b680) at /home/travis/src/storage/innobase/row/row0purge.cc:791
      #14 0x000056466b01f763 in row_purge_record_func (node=0x56466d18b680, undo_rec=0x56466d91ce50 "", thr=0x56466d18b5c8, updated_extern=false) at /home/travis/src/storage/innobase/row/row0purge.cc:1102
      #15 0x000056466b01f9df in row_purge (node=0x56466d18b680, undo_rec=0x56466d91ce50 "", thr=0x56466d18b5c8) at /home/travis/src/storage/innobase/row/row0purge.cc:1163
      #16 0x000056466b01fd1b in row_purge_step (thr=0x56466d18b5c8) at /home/travis/src/storage/innobase/row/row0purge.cc:1249
      #17 0x000056466afb0468 in que_thr_step (thr=0x56466d18b5c8) at /home/travis/src/storage/innobase/que/que0que.cc:1049
      #18 0x000056466afb0663 in que_run_threads_low (thr=0x56466d18b5c8) at /home/travis/src/storage/innobase/que/que0que.cc:1111
      #19 0x000056466afb080d in que_run_threads (thr=0x56466d18b5c8) at /home/travis/src/storage/innobase/que/que0que.cc:1151
      #20 0x000056466b06b608 in srv_task_execute () at /home/travis/src/storage/innobase/srv/srv0srv.cc:2538
      #21 0x000056466b06b756 in srv_worker_thread (arg=0x0) at /home/travis/src/storage/innobase/srv/srv0srv.cc:2585
      #22 0x00007f98a7a70184 in start_thread () from /lib/x86_64-linux-gnu/libpthread.so.0
      #23 0x00007f98a6f7cffd in clone () from /lib/x86_64-linux-gnu/libc.so.6


      Attachments

        Issue Links

          Activity

            serg, the assertion failure here seems to be local to open_purge_table(). InnoDB should be OK if opening the table fails; it should assume that the table is no longer available, and that the old undo log records can be discarded.

            It looks like we should seriously come up with some InnoDB data format change that removes the need to compute virtual columns during the purge of history.
            Ideally virtual column values should only be computed once, at the SQL layer. (Unfortunately, InnoDB’s SET NULL or CASCADE handling related to FOREIGN KEY still requires InnoDB to evaluate indexed virtual column values in connected tables.)

            Currently, purge evaluates indexed virtual columns inside row_purge_poss_sec(), which is the only caller of row_vers_old_has_index_entry(also_curr=true, …). This happens only when there is only one version of the clustered index record, and it is not delete-marked.

            In the test case, there must exist exactly 1 record in clustered index before the ALTER TABLE statement, with pk=1. The column c would be updated. The ‘only one version’ condition should only hold before the REPLACE statement is executed, or (in 10.3 MDEV-12288) after we have reset the DB_TRX_ID,DB_ROLL_PTR in the clustered index record as part of purge.

            It looks like the stack trace must be for the delete-marked record (vd=NULL,c='foo',pk=1) in the secondary index.

            The virtual column evaluation could be avoided in this case, because no base column of an indexed virtual column is being updated. There is INDEX(vd,c), but only the persistent column c is being updated, and vd would remain unchanged.

            The task in purge is to find out if the delete-marked record in a secondary index corresponds to any still visible version in the clustered index, that is, if the secondary index record can be removed. In this case, we could also notice a mismatch in the persistent column c already, so we should not bother to evaluate any virtual columns.

            In the general case, I believe that the only way to avoid evaluating virtual columns in purge is to change the format of indexes on virtual columns, so that these index entries will include DB_TRX_ID and possibly DB_ROLL_PTR. This would also simplify MVCC and implicit locking. This should probably be an option for all secondary indexes in InnoDB.

            marko Marko Mäkelä added a comment - serg , the assertion failure here seems to be local to open_purge_table() . InnoDB should be OK if opening the table fails; it should assume that the table is no longer available, and that the old undo log records can be discarded. It looks like we should seriously come up with some InnoDB data format change that removes the need to compute virtual columns during the purge of history. Ideally virtual column values should only be computed once, at the SQL layer. (Unfortunately, InnoDB’s SET NULL or CASCADE handling related to FOREIGN KEY still requires InnoDB to evaluate indexed virtual column values in connected tables.) Currently, purge evaluates indexed virtual columns inside row_purge_poss_sec() , which is the only caller of row_vers_old_has_index_entry(also_curr=true, …) . This happens only when there is only one version of the clustered index record, and it is not delete-marked. In the test case, there must exist exactly 1 record in clustered index before the ALTER TABLE statement, with pk=1 . The column c would be updated. The ‘only one version’ condition should only hold before the REPLACE statement is executed, or (in 10.3 MDEV-12288 ) after we have reset the DB_TRX_ID,DB_ROLL_PTR in the clustered index record as part of purge. It looks like the stack trace must be for the delete-marked record (vd=NULL,c='foo',pk=1) in the secondary index. The virtual column evaluation could be avoided in this case, because no base column of an indexed virtual column is being updated. There is INDEX(vd,c) , but only the persistent column c is being updated, and vd would remain unchanged. The task in purge is to find out if the delete-marked record in a secondary index corresponds to any still visible version in the clustered index, that is, if the secondary index record can be removed. In this case, we could also notice a mismatch in the persistent column c already, so we should not bother to evaluate any virtual columns. In the general case, I believe that the only way to avoid evaluating virtual columns in purge is to change the format of indexes on virtual columns, so that these index entries will include DB_TRX_ID and possibly DB_ROLL_PTR . This would also simplify MVCC and implicit locking. This should probably be an option for all secondary indexes in InnoDB.

            julien.fritsch the problem is tha it is the bug in 10.2+. What'd we do in 10.2-10.5 with it?

            nikitamalyavin Nikita Malyavin added a comment - julien.fritsch the problem is tha it is the bug in 10.2+. What'd we do in 10.2-10.5 with it?

            So we are having a three thread race condition with a deadlock backoff
            For visuals, the situation can be described by the picture attached.

            More precisely, the following happens:
            T1: NOCOPY ALTER TABLE begins, and eventually it holds MDL_SHARED_NO_WRITE lock;
            T2: FLUSH TABLES begins. it sets share->tdc->flushed = true
            T3: purge on a record with virtual column begins. it is going to open a table. MDL_SHARED_READ lock is acquired therefore.
            Since share->tdc->flushed is set, it waits for a TDC purge end.
            T1: is going to elevate MDL LOCK to exclusive and therefore has to set other waiters to back off.
            T3: receives VICTIM status, reports a DEADLOCK, sets OT_BACKOFF_AND_RETRY to Open_table_context::m_action

            nikitamalyavin Nikita Malyavin added a comment - So we are having a three thread race condition with a deadlock backoff For visuals, the situation can be described by the picture attached. More precisely, the following happens: T1: NOCOPY ALTER TABLE begins, and eventually it holds MDL_SHARED_NO_WRITE lock; T2: FLUSH TABLES begins. it sets share->tdc->flushed = true T3: purge on a record with virtual column begins. it is going to open a table. MDL_SHARED_READ lock is acquired therefore. Since share->tdc->flushed is set, it waits for a TDC purge end. T1: is going to elevate MDL LOCK to exclusive and therefore has to set other waiters to back off. T3: receives VICTIM status, reports a DEADLOCK, sets OT_BACKOFF_AND_RETRY to Open_table_context::m_action

            here the deterministic test goes

            --source include/have_innodb.inc

            CREATE TABLE t1 (
              pk SERIAL,
              c VARCHAR(128),
              d DATE,
              vd DATE AS (d) VIRTUAL,
              PRIMARY KEY(pk),
              KEY(vd,c)
            ) ENGINE=InnoDB;
            INSERT IGNORE INTO t1 (pk,c) VALUES (1,'foo');

            --connect (con1,localhost,root,,test)
            set global innodb_debug_sync="after_open_table_mdl_shared wait_for purge";
            REPLACE INTO t1 (pk,c) VALUES (1,'bar');

            --connection default
            set debug_sync="alter_table_before_rename_result_table wait_for purge";
            --send
              ALTER TABLE t1 ADD FULLTEXT KEY(c), ALGORITHM=COPY;
            --connection con1
            set debug_sync="after_flush_unlock signal purge";
            FLUSH TABLES;

            # Cleanup
            --disconnect con1
            --connection default
            --reap
            DROP TABLE t1;



            nikitamalyavin Nikita Malyavin added a comment - here the deterministic test goes --source include/have_innodb.inc   CREATE TABLE t1 ( pk SERIAL, c VARCHAR (128), d DATE , vd DATE AS (d) VIRTUAL, PRIMARY KEY (pk), KEY (vd,c) ) ENGINE=InnoDB; INSERT IGNORE INTO t1 (pk,c) VALUES (1, 'foo' );   --connect (con1,localhost,root,,test) set global innodb_debug_sync= "after_open_table_mdl_shared wait_for purge" ; REPLACE INTO t1 (pk,c) VALUES (1, 'bar' );   --connection default set debug_sync= "alter_table_before_rename_result_table wait_for purge" ; --send ALTER TABLE t1 ADD FULLTEXT KEY (c), ALGORITHM=COPY; --connection con1 set debug_sync= "after_flush_unlock signal purge" ; FLUSH TABLES;   # Cleanup --disconnect con1 --connection default --reap DROP TABLE t1;
            nikitamalyavin Nikita Malyavin added a comment - sanja Please review the fix: https://github.com/MariaDB/server/commit/cd63fa047994b58d070c5f9db76397b23cd3261c

            OK to push

            sanja Oleksandr Byelkin added a comment - OK to push

            Removing the remaining effort since this issue is closed.

            julien.fritsch Julien Fritsch added a comment - Removing the remaining effort since this issue is closed.
